The Ultimate Stereo Power Amplifier

This amplifier gives you the power and versatility you need to create a professional sound system. Its wide frequency response makes it suitable for amplifying any type of audio including music or vocals. It can be used in meeting halls, restaurants, schools, stores, and at home –the perfect solution for paging systems anywhere. Get the power you need with 2 x 75 Watt to handle all your audio needs.

110/220 Voltage Selector

This amplifier has selectable input voltage from 110 V/60 Hz (the standard in USA and Canada) to 220 V/50 Hz (for European operation). Please make sure the switch is in the proper position before operating.

Compatibility

Compatible with CD players, walkmans, and computerized devices, including MP3s, via 3.5 millimeter to RCA converter.

RCA L/R Line Input

Lets you connect the desired line input source.

Take Control

Use the control center panel located on the face of the unit to make adjustments to microphone volume, master volume, balance, bass, and treble.

Push Type Speaker Terminals

Lets you easily connect speaker wires directly to the amplifier.

Replaceable Power Fuse

The amplifier uses a fuse for protection against surges and short circuit. If the amplifier suddenly turns off and will not turn on, check the fuse and replace it if necessary. (Replacement fuse to use: 1.5-amp, 250-volt, fast-acting 5 x 20 millimeter fuse –not included)

Additional Features

• Harmonic Distortion: 0.3%
• 2 x 75 Watt RMS at 4 Ohm
• Blue LED Output Level Display
• Frequency Response: 20 Hz-40 kHz
• Power Fuse: 1.5 A, 250V Fast-Acting (5 x 20 millimeter)
• Power Requirement: 120 V AC 50 Hz/230 V AC 50 Hz
• Tone Controls: Bass and Treble: +/-10dB (100 Hz/10 kHz)
• Dimensions: 8.27 x 2.72 x 5.39 inch (190 x 70 x 137 millimeter)
